ZETA (R100-SA) R100 Addressable Sounder with SCI

Model: R100-SA
Trade Only

ZETA (R100-SA) R100 Addressable Sounder with SCI

Model: R100-SA
Trade Only
Product Description

ZETA, R100-SA, R100 Addressable Sounder with SCI

The Zeta R100-SA Addressable Sounder represents an exciting advancement in fire alarm notification technology, combining high-performance audio output with intelligent addressable functionality. Operating on the Zeta Fyreye II protocol, this low-power consumption device delivers impressive 100dB sound output with exceptional versatility through 16 selectable alarm tones and 4 adjustable volume settings, making it suitable for a wide range of commercial and public building applications.

Designed with both performance and practicality in mind, the R100-SA features a softly styled, compact design housed in flame-retardant ABS material. The device comes supplied with a shallow indoor mounting backbox as standard, with rear wiring entry for neat installations. For outdoor or exposed applications, the R100-SA can be easily upgraded to weatherproof Type B specification using the optional R100-SM/WP outdoor backbox, which features two threaded 20mm cable entry points for enhanced environmental protection achieving IP33C rating.

Key Features:

  • Addressable operation on Zeta Fyreye II protocol only
  • High output 100dB sound pressure level (anechoic) +/- 3dB
  • 16 selectable alarm tone patterns for versatile applications
  • 4 adjustable sounder volume settings: Off, Low, Medium, High
  • Built-in short circuit isolator for enhanced loop integrity
  • Extremely low quiescent current of 700μA (0.7mA)
  • Low alarm current consumption: 2.6mA to 5.5mA depending on settings
  • Wide operating voltage range: 17-28V DC
  • Type A (indoor) certified with standard shallow backbox
  • Type B (outdoor) capability when used with optional R100-SM/WP backbox
  • IP21C rating for indoor use (standard configuration)
  • IP33C rating for outdoor use with R100-SM/WP backbox
  • Housed in UL V0 flame retardant ABS for fire safety
  • Attractive red and grey housing colour scheme
  • Compact dimensions: 100x100x103mm (indoor), 120x120x118mm (outdoor)
  • Lightweight design at just 305g
  • Pluggable 4-way terminal connector for easy first fix installation
  • Earthing point included for proper grounding
  • Standard shallow backbox with rear wiring entry supplied
  • Optional outdoor backbox with 2 x 20mm threaded cable entries available
  • Wide operating temperature range: -25°C to 70°C
  • Suitable for environments up to 95% RH non-condensing humidity
  • EN54 Part 3 Type A and B compliant (certification pending)
  • Surface mount only installation
  • Softly styled, versatile and compact design
  • Reliable performance in demanding applications

For more details, please refer with our attached datasheet.

Contact us on sales@hunters-wholesalers.co.uk for more specific product information and pricing installation and training.

Name Download
Datasheet for ZETA (R100-SA) R100 Addressable Sounder with SCI Download
